CAPE AGAMEMNON
BUILT: 2010
CLASS: ABS
FLAG: LIBERIA
BUILDER: Sungdong Shipbuilding & Marine Enginering Co. Ltd., Republic of Korea
VESSEL MAIN PARTICULARS
Type of vessel:
Bulk Carrier, +A1 BC-A (Hold 2,4, 6 & 8 may be empty), (E), +AMS, +ACCU, TCM, ESP, CSR, Safeship-CM, GRAB(20), RW, UWILD
Summer deadweight:
179,221 MT
Summer draft:
18.322 m
LOA:
292 m
Beam:
45 m
GT / NT:
92,744 / 58,728
Grain capacity:
H1:683,833.46, H2:788,248.38, H3:791,221.87, H4:791,221.87, H5: 819,424.18, H6: 819,925.65, H7:791,292.5, H8:778,349.67, H9:714,610.21 cft
Bale capacity:
H1:649,641.79, H2:748,833.66, H3:751,662.37, H4:751,658.84, H5:778,452.09, H6:778,928.83, H7:751, 729.47, H8:739,432.9, H9: 678,882.35 cft
TPC at summer draft:
122.4
CARGO ARRANGEMENTS
Cargo holds / hatches:
9 holds / 9 hatches strengthened for heavy cargoes
Ausralian hold ladder:
Fitted in all tanks
CO2:
Not Fitted
El. Ventilation:
Natural Ventilation
Logs Fitted:
No
Cranes / SWL:
None
Grabs / capacity:
None
Tank top strength:
No.1: 29.0MT /m² /No. 2,4,6,8: 23.0MT /m² /No. 3,5,7,9: 29.7MT /m²
Deck strength:
3.0 MT/ m²
Hatch covers strength:
1.75 MT/ m²
Hatch covers type:
MAC GREGOR side rolling type
Hatch dimensions:
No 1, 9: 15.64 x 17.2 m / No. 2,8: 15.64 x 20.6 m
Hold dimensions:
L X W on tanktop x Hmax height No.1,4: 25.74 x 24.10 m / No. 7,9: 25.74 x 24.10 m No. 5,6: 26.68 x 24.10 m
A60 Bulkhead:
Yes
PROPULSION
Main engine:
MAN B & W 6S70MC-C MK VII
Propeller type:
4 bladed solid fixed prope
Generators:
3 HYUNDAI - HIMSEN 7H17/28 x 690 Kwe
